3.JUNG J 630
JUNG J-Series (CNC control)
High-precision, CNC forming grinder with a very open design of effective conventional forming grinding operation, friendly interface with sophisticated modern control systems, drives and measuring systems. Simple protective cover, removable metal plate can be surrounded by danger zone to ensure safety, but also a simple close. So that the processing of small parts with the highest accuracy and shortest processing time.
4.JUNG C 740
JUNG C740 a machine
C Series grinders are widely used. Abrasive industry for workers from the simple to the variety of profile grinding surface grinding and even mass-produced high-speed grinding can do the job.
JUNG C740 an ideal platform for custom grinding task
A variety of exquisite detail and C series integrated concept for almost any grinding work provides the perfect environment. Thanks to all control elements --- including ergonomic design with full opening door completely shield the work area --- optimized to facilitate safe operation. When the door opens, you can enter the work area at the top, making the grinding machine table can be unloaded at any time out.
Technical parameters
Work area (L * W) 880 * 510MM
Table size 800 * 400MM
Table to spindle center distance 735MM
Maximum table load capacity, including electromagnetic card volume 800KG
Longitudinal movement X axis machine 880MM
Feed rate of 1 ... 40000MM/MIN
Y-axis vertical grinding wheel spindle moves 585MM
Feed rate of 0.1 ... 5000MM/MIN
Z-axis saddle lateral movement 460MM
Feed rate of 0.1 ... 5000MM/MIN
Grinding spindle motor 15KW
Three-phase, variable speed 1500 ... 4300RPM
Wheel size, diameter * width * ID 400 * 100 * 127MM
5.JUNG S 320
High Speed Grinder S 320
Based on the traditional HF / JF Series has proven structure, JUNG developed new tools for fast, economical grinding. Even the most vulnerable to a hard metal or ceramic parts (grinding time is reduced to 1 / 5). S320 of the grinding table (X axis) by a Siemens linear motor drive. Hydraulic drive past the table only allows a maximum speed 60-80 times / min. A new generation of machine is easy to achieve 10 times the number of trips (up to 600 from / min). Is a possible quick, slow is another. X-axis feed speed can be achieved 1 mm / min. Linear motor drive can also be cut for grinding, combined with the Y-axis feed control, and even the profile grinding.
Despite the high velocity, X-axis for the accuracy of almost no deviation, and linear motor driven entirely built in the Siemens 840D control system. Therefore, we can use stable oscillation grinding process with the base of the punch. Deviation for the accuracy of less than 0.001 mm.
Giving users the following benefits:
Elected with the outline of oscillating grinding, forming punch processed
With the base of the punch can grind a small arc, or even in pairs clamping.
Grinding wheel diameter can be 80-150 mm, maximum width 16 mm.
S320 machine to be closed casing. 200X150 mm grinding range, compact structure.
Needless to say, different equipment and other JUNG, S320 can be programmed according to the needs of users. Multiple software modules to choose from.
6.JUNG VARIO
JUNG VARIO ---- to achieve optimal results
VARIO design is based on a new modular horizontal rails, to provide customers with the highest levels of quality and accuracy. Vertical position in each slide are supported, and to ensure the table with different accessories, such as trimming, rotary table and fixture systems absolute variability. When you need minimal installation space, the compact structure of the work area to ensure maximum flexibility. Optional grinding cycle and control system through a standard P automatic molding trim, making VARIO as a simple molding grinder. D control system represents a modular system Qiongge the highest stage of development. It is suitable for forming the CNC dresser PA37K and PA130TM joint use of complex workpieces.
CNC dressing unit PA37K head forming the flexibility to use a single diamond grinding wheel or diamond wheel to make Qiongge be driven precision surface grinding and forming.
Technical parameters
Work area (L * W) 600 * 300MM
Table size 600 * 300MM
Table to spindle center distance 620MM
Maximum table load capacity, including electromagnetic card volume 250KG
Longitudinal movement X axis machine 750MM
Feed rate of 1 ... 50000MM/MIN
Y-axis vertical grinding wheel spindle moves 485MM
Feed rate of 0.1 ... 5000MM/MIN
Z-axis saddle lateral movement 335MM
Feed rate of 0.1 ... 5000MM/MIN
Grinding spindle motor 9.3KW
Three-phase, variable speed 800 ... 4200RPM
Wheel size, diameter * width * ID 300 * 50 * 76.2MM
